| 제품규격 Product Dimensions | |
|---|---|
| 폭 Width | 최대 15mm Max 15mm |
| 높이 Height | 최대 60mm Max 60mm |
| 길이 Length | 최대 180mm Max 180mm |
| * 이 외의 특수 사양 제작 가능함. Others are available for your option. | |
| 필름규격 Reel Width | |
|---|---|
| 필름폭 Standard | 최대 520mm Max 520mm |
| 롤외경 Outer diameter | 최대 350mm Max 350mm |
| 보빈규격 Core diameter | 76mm |
| 무게 Weight | 최대 40kg Max 40kg |
| 전기사양 Electrical specifications | |
|---|---|
| 전기 Mains | 380V, 3-P |
| 소비전력 Consumption | 10kW |
| 히터사양 Heater elements | 220V |
| 구동모터 Motor | 2.5kW, 3축 서보모터(제품공급부, 필름공급부, 앤드씰링부) 3 Axis servo motor |
| 인자기 Printer-coder |
| 각종 자동 공급장치 Defferent types of automatic product feeding systems |
| M-씰링 장치 Gusset device |
| 조정포머 Adjustable folding box for a variety of products |
| 습한 작업 환경에 따른 재질 변경 Stainless steel modification for humid environments |
| 필름 자동 연결장치 Film auto splicer |
| 벨트방식 제품공급 Carrier less - Belt type |
